Entaniya HAL220 PL Super-Wide Fisheye Lens

Home/Lenses/Entaniya HAL220 PL Super-Wide Fisheye Lens

The Entaniya HAL220 range of 220° 8K resolution fisheye lenses enables the capture of unique wide-angle images well beyond a normal field of view.  Despite having a 220° angle of view, the lens quality reveals few aberrations or fringing making it one if the best quality fisheye lenses in the world.  The Entaniya HAL 220 PL-mount lens features interchangeable spacers to provide an optimised coverage of a wide range of large format camera sensors with an image circle from 22.6 – 29.8mm diameter.  Two adjustable iris options are available.  Please contact us or refer to the datasheet tab for technical details including sensor coverage and image circle information.

Because of the specialist nature of this camera we suggest you contact us for current pricing and a quotation.

Call for price

Product Description

Because of the specialist nature of this camera we suggest you contact us for current pricing and a quotation.

The Entaniya HAL220 range of 220° 8K resolution fisheye lenses enables the capture of unique wide-angle images well beyond a normal field of view.  Despite having a 220° angle of view, the lens quality reveals few aberrations or fringing making it one if the best quality fisheye lenses in the world.

The Entaniya HAL 220 PL-mount lens is designed to provide a maximum φ29.8mm Image Circle and is compatible with a wide range of cameras including a wide range of ARRI and RED cameras, Sony Cinealta VENICE, Blackmagic URSA MiniPro ,Super 35, Fujifilm GFX 50S, ZCAM E2, and many more large format cameras.  It features a PL mount, 9 or 11 blade adjustable iris aperture, and is supplied with interchangeable spacer rings allowing 14 steps in image circle diameter providing perfect sensor coverage.  An iris drive gear is also included along with a lens support ring.  Please contact us or refer to the datasheet tab for technical details including sensor coverage and image circle information.

The HAL range features interchangeable rear lens groups and camera mounts, which provides a flexible, low cost solution allowing the lenses to fit a wide selection of large format cameras with no compromise on image quality.  These lenses are designed and used in a variety of applications including Cinema and Film special visual effects,  Planetarium and full-dome imaging, 360VR / 3D VR180, specialist industrial applications, etc.

It is also perfect for industrial imaging applications where a wide range of images is required from with a single camera, reducing the number of cameras and greatly contributing to system simplification and cost reduction.  Entaniya fisheye lenses are used in a variety of applications including 3D scanners, omnidirectional recording surveys, tunnel surveys, pipe and pipe surveys, traffic surveys, and for security cameras.



Focal Length 6.14 – 8.03mm (Fixed focal lengths adjusted by spacer rings)
Spacer Ring Focal Lengths 6.14, 6.20, 6.30, 6.40, 6.51, 6.63, 6.74, 6.87, 6.99, 7.12, 7.26, 7.40, 7.55, 7.70 & 8.03mm
Field of View 220 degrees
Image Circle (Diameter) 180 deg. = 19~25mm, 220 deg. 22.6~29.8mm
Aperture T2.9 – T16 9 blade aperture or T2.9 – T22 11 blade
Resolution Suitable for 8K cameras
Minimum Object Distance To be confirmed
Adjustment Manual Focus, Adjustable Iris manual or gear driven
Lens Elements 17 Elements in 12 groups
Mount Options PL mount
Lens Support Mount Included
Weight 1.5 KG
Dimensions 102mm Diameter
  • Focal length 6.14 – 8.03mm via interchangeable spacer rings, 220° angle of View
  • 8K Ready
  • Choice of 9 blade T2.9 – T16 aperture or 11 blade T2.9 – T22 aperture
  • Focus by thread adjustment and locking screws
  • Selection of camera rigs available
  • Weight 1.5 KG
  • Japanese lens technology & quality
  • Lenses are also available for hire from SeeSense

Cinema and Film special visual effects
Planetarium and full-dome imaging
360VR / 3D VR180
Specialist industrial applications

  • Entaniya HAL 220 PL mount lens
  • 14 spacer rings
  • Front & rear lens cap
  • ND Filter set – ND 1.2
  • Tool set
  • Hard storage case
  • Lens cleaning cloth
  • Warranty card
  • Instruction Sheet
